First select a product category. Here you can choose between linear encoders, angle encoders or length gauges.
Select the accuracy of the incremental length gauge that meets your requirements. You can choose between two accuracy classes, SPECTO for ±1 µm or METRO for ±0.5 µm.
The position detection can be incremental or absolute. The incremental measuring method provides a relative position as well as direction of movement, which requires an assignment to a reference point (starting point) at the beginning of the measurement. This is done by homing the axis. The absolute measuring method provides concrete position information at any axis position. A reference run at the beginning of the measurement is not necessary.
At this point you can select the type of bolt actuation. You can choose between two variants, spring-driven or pneumatic. With spring-driven length gauges, the built-in spring extends the measuring bolt into the measuring position and builds up the measuring force. The measuring bolt is extended in the rest position. On length gauges with pneumatic bolt actuation, the bolt extends when compressed air is applied. When the compressed air connection is vented, the built-in spring retracts the measuring bolt.
Discover our series
Optical encoders for control and positioning tasks with special features. Precise measurement in the micrometer and nanometer ranges. For a wide range of linear and rotary applications with special size and accuracy requirements.
According to the selection you have made, we recommend the displayed product series. Clicking the display provides you with a detailed overview of the product variants and their features.
The NUMERIK JENA brand, a specialist for particularly small length and angle measuring systems, is expanding its product portfolio with an innovative length gauge platform.
The new generation stands for reliability, accuracy and quality of the measuring systems. The proven SPECTO and METRO product families have been redesigned, standardized and specifically further developed.
The new platform design offers many advantages for users in a wide range of (metrology) applications such as quality assurance or production metrology.
Read more
With the LIKselect incremental linear encoder, NUMERIK JENA launches a product with a completely new design that has been specially developed to meet customer requirements.
The LIKselect supplements the new LIK series and opens up a wide range of expandable integration options for users. Due to its modular design, the encoder can be adapted to a wide variety of mounting situations and space conditions.
Show more
Its extremely compact design as well as many configuration options make this product series an all-round talent for incremental path measurements
The outstanding characteristics of this encoder are based on a combination of incremental and absolute measuring technology
The flat and lightweight design of the encoder enables users a wide range of applications for rotary measuring tasks
The LIA series offers a wide range of application possibilities and is configurable with expandable features such as optional switching sensors
We have specialized in developing individual solutions together with our customers for 25 years. A large number of our customers receive specially developed encoder solutions from us that make their products unique and set them apart from competitors.
Are you interested in such a solution, and do you have questions?
Let us advise you
22.01.2025 - 24.01.2025
Asia's Leading Electronics Tech. Show Launched more than 30 years ago, NEPCON JAPAN has grown together with the Japanese & Asian electronics...
11.03.2025 - 14.03.2025
International Trade Fair for Machine Tools, Manufacturing and Automation
The Intec International Trade Fair for Machine Tools, Manufacturing and...
A meeting place for the entire industrial ecosystem
Global Industrie is the cornerstone of the reindustrialization process, and a symbol of the...
With the help of a high-resolution, optical linear measuring system such as the LIKselect from NUMERIK JENA, a vehicle assistance system can be precisely adjusted. The challenging aspect here is the constantly advancing miniaturization of the alignment units with very tight installation spaces for the measuring systems.
Here, every millimeter is crucial, and customer-specific requirements are often placed on the measuring systems, which are rarely found in suppliers' catalogs. NUMERIK JENA offers the optimal solution for this with the LIKselect.
With the help of a high-resolution, optical linear measuring system such as the LIKselect from NUMERIK JENA, a vehicle assistance system can be precisely adjusted.
High-precision positioning of axes is the key to many achievements of modern technology. Particularly in industrial semiconductor production or in the fields of medicine, research and inspection of materials, positioning tasks are becoming increasingly important.
The challenges here are the constant miniaturization of assemblies, the highly accurate and reproducible measurement of translations, and the reliability of integrated systems.
Due to the very small size and modular design of the LIKselect optical linear measuring system from NUMERIK JENA, it is ideally suited for integration in very small, flat positioning tables.
In a customer-specific inspection system, components are measured for their quality and then sorted. Special camera and microscope techniques are used to monitor the specifications of the components and ensure appropriate sorting. The positioning of the inspection technology is done by high-resolution measurement technology, which was individually adapted to the requirements of the inspection system and the available installation space.
The choice fell on the RIK 4 rotary optical measuring system from NUMERIK JENA, as this system was able to meet all the required characteristics.
Encoders with customer-specific graduated disk segments enable measurement tasks in very limited installation spaces
MRIs generate very strong magnetic fields as well as alternating magnetic fields in the radio frequency range, with which certain atomic nuclei (mostly the hydrogen nuclei/protons) in the body are resonantly excited. Any ferromagnetic materials in the direct vicinity of the measuring range would negatively affect the measuring result.
Therefore, NUMERIK JENA has developed measuring systems with non-magnetic components especially for applications of this kind.
Non-magnetic versions of measuring systems for controlling patient tables in magnetic resonance imaging (MRI)
When assembling body parts in automotive manufacturing, precise distances and angles must be maintained between the individual components to ensure correct alignment and fit. These processes require maximum precision and accuracy to ensure high quality of the end products.
For this purpose, angle measuring systems such as the Kit R4 from NUMERIK JENA are used in robot arms to ensure precise positioning of the body parts.
With the help of Kit R4 measuring systems, the movements required to position a body part at the intended location can be controlled precisely and quickly.
Referencing is an important step during the printing process where the print heads are set to a specific start position in the press. This is necessary in order to be able to print surfaces repeatedly and accurately. Absolute measuring encoders are often used for this purpose, as they can always provide precise position information at any point without having to perform an additional reference run.
The absolute measuring encoder LAK from NUMERIK JENA can detect the position of the print heads with high accuracy and forward it to the control unit to control the positioning of the print heads to their start position.
